Heavy-duty ARC welding solutions powered by advanced IGBT technology for high performance, energy efficiency, and long-lasting durability across all welding tasks.
| Technical Specification | Model VMW – R 400 | Model VMW – R 600 |
|---|---|---|
| Input Supply Voltage | 415-440 V AC 3 Phase | 415-440 V AC 3 Phase |
| Input Current | 30 Amps | 40 Amps |
| Frequency | 50 Hz | 50 Hz |
| Max Hand Weld Current @ 60% Duty Cycle | 400 Amp | 600 Amps |
| Max Hand Weld Current @ 100% Duty Cycle | 300 Amp | 500 Amps |
| Open Circuit Voltage | 90 VDC | 90 VDC |
| Weld Current Range | 30 To 400 Amps | 30 To 600 Amps |
| KVA at Max. Rated Amp | 30 KVA | 42 KVA |
| Cooling System | Forced Air | Forced Air |
| Insulation | "H" Class | "H" Class |
| Dimension in mm (L x W x H) | 680 x 560 x 790 | 700 x 580 x 810 |
| Weight Approx | 270 Kgs. | 300 Kgs. |
We specialize in providing high-quality welding and cutting equipment tailored to meet industrial demands.
